Monitor Section Picture size 10.1 inches(diagonal) wide W x H 223.7 x 125.8 (mm) Display system AAS LCD panel Drive system TFT active matrix system Number of pixels 2,764,800 1280H x 720V x RGB Effective pixels 99.99% Pixel arrangement RGB striped arrangement Back lighting LED USB I/F Section USB Standard USB2.0 High Speed File System FAT 16/32, exFAT, NTFS Maximum Power Supply Current DC5V=1.5A D/A Converter 24/32Bit Audio Decoder MP3 / WMA / AAC / WAV / FLAC / DSD / Vorbis Video Decoder MPEG1/2,MPEG4 / WMV / H.264 / MKV Frequency response 192k Sampling 20 - 88,000 Hz 　　　　　 96k Sampling 20 - 44,000 Hz 　　　　　 48k Sampling 20 - 22,000 Hz 　　　　　 44.1k Sampling 20 - 20,000 Hz Total harmonic distortion 1kHz 0.010% Signal to Noise ratio 98.5dB Dynamic range 89dB Wireless Mirroring Section Mode Sink Copyright protection HDCP2.2 Touch Control UIBC Wi-Fi IEEE Standard 802.11 a/b/g/n/ac Frequency Range Dual Band ( 2.4GHz / 5GHz ) Channels Auto(1-11ch) Auto(149,153,157,161ch) Transfer rates (MAX) 11a: 54 Mbps / 11b: 11 Mbps / 11g: 54 Mbps / 11n: 300 Mbps / 11ac: 867 Mbps Output Power 2.4GHz/SISO 11b:13dBm±2dB / 11g:11dBm±2dB / 11n(20MHz):10dBm±2dB Output Power 5GHz/SISO 11a:6dBm±2dB / 11n(20MHz):6dBm±2dB / 11n(40MHz):5dBm±2dB / 11ac(20MHz):6dBm±2dB / 11ac(40MHz):5dBm±2dB / 11ac(80MHz):5dBm±2dB Output Power 5GHz/MIMO 11n(20MHz):9dBm±2dB / 11n(40MHz):8dBm±2dB / 11ac(20MHz):9dBm±2dB / 11ac(40MHz):8dBm±2dB / 11ac(80MHz):8dBm±2dB Bluetooth Section Technology Bluetooth Ver5.0 Frequency 2.402 – 2.480 GHz RF Output Power (E.I.R.P.) +4dBm (MAX), Power Class 2 Maximum Communication range Line of sight approx.10m(32.8ft) Audio Codec SBC / AAC / LDAC Multi Profile Support Multi Profile Profile HFP (V1.7) (Hands Free Profile) SPP (Serial Port Profile) A2DP (Advanced Audio Distribution Profile) AVRCP (V1.6) (Audio/Video Remote Control Profile) PBAP (Phonebook Access Profile) HDMI Connector Type Type A Input Resolution VGA (640x480p @59.94Hz/60Hz) 480p (720x480p @59.94Hz/60Hz) 720p(1280x720p 59.94Hz/60Hz) Input Audio Type 32K/44.1K/48K/88.2K/96K/176.2K/192K 16/20/24-bit Linear PCM DSP Section Graphics equalizer BAND 13Band frequency (Hz) (BAND1-13) 62.5/100/160/250/400/630/1k/1.6k/2.5k/4k/6.3k/10k/16k Gain -9/-8/-7/-6/-5/-4/-3/-2/-1/0/1/2/3/4/5/6/7/8/9[dB] 2Way X'Over HIGH PASS FILTER frequency Through/30/40/50/60/70/80/90/100/120/150/180/220/250[Hz] SLOPE -6/-12/-18/-24[dB/Oct.] LOW PASS FILTER frequency 30/40/50/60/70/80/90/100/120/150/180/220/250/Through[Hz] SLOPE -6/-12/-18/-24[dB/Oct.] 3Way X'Over HIGH PASS FILTER frequency 250/300/1k/1.6k/2.5k/4k/5k/6.3k/8k/10k/12.5k SLOPE -12/-18/-24[dB/Oct.] Band PASS FILTER frequency Through/50/60/70/80/90/100/120/150/180/220/250/300[Hz]
250/300/1k/1.6k/2.5k/4k/5k/6.3k/8k/Through SLOPE -12/-18/-24[dB/Oct.] LOW PASS FILTER frequency 30/40/50/60/70/80/90/100/120/150/Through[Hz] SLOPE -12/-18/-24[dB/Oct.] Position Front / Rear /Subwoofer Delay 0 - 6.1m (0.01m Step) Gain -8 to 0dB Subwoofer Level -50 to +10dB FM Frequency Range 87.5MHz - 108.0MHz (Frequency step) (50kHz) Usable sensitivity
S/N30dB 7.3dBf (0.7μV) /75Ω Frequency response
